JST 02ASR-36S Earphone Terminal Cable

Product Details

Our JST 02ASR - 30S Connecting Cable, crafted by pros, offers OEM & ODM with full customization.

1、Basic Product Specifications

Basics: Standard 30AWG wire, JST - 02ASR - 30S housing. Dimensions are tailored to your needs. It uses ROHS - compliant and UL - approved materials, with tin - plating for better conductivity and corrosion resistance.
Production: Machine - stripped wires, crimped terminals, and manual housing installation and welding ensure precision and stability.
Services: Delivery date is negotiable. We offer standard packaging or custom options. Choose from express, sea, or air freight. MOQ is flexible based on your custom needs.

2、Specifications JST-02ASR-30S Housing

Current rating: 0.7 A DC

Voltage rating: 50 V DC

Temperature range: -25'℃ to +85℃

(including temperature rise in applyingelectrical current)

Contact resistance: Initial value/ 30 mΩ max.

After environmental testing/ 40 m max.

Insulation resistance:100 M min.

Withstanding voltage: 500 VAC/minute

Applicable wire：Conductor size/AWG #30

Conductor/ 7 strands,

tin-coated annealed copper

insulation O.D./ 0.54 to 0.58mm

JST 02ASR-36S Connecting Cable, (Earphone Terminal Cable).

Hot Tags : JST 02ASR-36S Connecting Cable Earphone Terminal Cable JST 02ASR-36S Connecting Cable, (Earphone Terminal Cable). wire-to-board connecting cable
